Product Details
＋
The Axisflying Argus PRO ESC 65A is a high-performance electronic speed controller designed for demanding FPV drone applications. This ESC is part of the Argus PRO series, which integrates advanced technology with robust construction, ensuring reliable performance in various environments.
Features:
- IP54 Protection: Dustproof and splashproof design (not for underwater use).
- CNC Aluminum Cover: Enhances heat dissipation and stability during operation.
- High-Quality MOSFETs: Low internal resistance for improved power performance.
- Plug-and-Play Connectivity: Directly connects to various peripherals without soldering.
- Integrated Dual BEC: Supports direct connection for DJI O3 Air Unit.
- Up to 8 Motor Outputs: Compatible with X8 drone configurations.
- Status Indicator Lights: Easily check the working status of the flight controller.
Package Includes:
1× Axisflying Argus PRO ESC 65A 3-6S 32Bit
1× To FC Cable
1× Rubber Ring
1× XT60 Power Cord
1× Ruby 35V 470μF Capacitor
1× SH1.0 8P Plastic Case (for FC Line
Specification:-
| Model |
Argus PRO ESC |
|---|---|
| Continuous Current (A): |
65 |
| Mounting Holes (mm) |
M3, 30.5 x 30.5 |
| BEC Output |
5V @ 2A and 9V @ 2A |
| PWM Frequency Range (KHz): |
16-96 |
| Rated Voltage (Lipo) |
3-6S (11.1V – 22.2V) |
| Shipping Weight | 0.07 kg |
| Shipping Dimensions | 7 × 7 × 7 cm |
